Suitable for narrow spaces
■ Narrow body of 1.9m(6'3") with almost zero tail sweep -
Precision performance
■ 3 joysticks with variable proportional control, boom swing, boom extension, turntable rotation and
walking speed, smooth start and stop motion, accuracy in reaching the operation target -
Industry-Leading adaptability
■ Maximum allowable inclination angle up to 5°
AB15J
Engine Powered Articulated Boom Lifts
-
Working Heightm
-
Platform Capacitykg
-
Gradeability%
- SPECIFICATIONS
- Standard/Optional
- APPLICATIONS
Product Highlights
Dimensions
-
Max Platform Height
14.7m (48'3") -
Max Working Height
16.7m (54'9.5") -
Max Horizontal Extension
8.5m -
[A] Length-Stowed
7.35m -
[B] Width-Stowed
2.26m -
[C] Height-Stowed
2.22m -
[D] Wheelbase
2.03m -
Ground Clearance
0.32m -
Platform Dimensions(L×W×H)
1.83 × 0.85 × 1.1 m
Performance
-
Platform Capacity
(Unrestricted/2 Persons)250kg -
Turntable Rotation
355° non-continuous -
Platform Rotation
160° -
Drive Speed-Stowed
5km/h 4WD -
Drive Speed-Raised
1.1km/h -
Gradeability
40%(4WD) -
Turning Radius-Inside
1.8m -
Turning Radius-Outside
4.5m -
Turntable Tailswing
0m -
Tilt Rating
5° -
Max Operating Noise Level
-
Drive×Steer
4 WD x 2 WS -
Tyres Spec/Type
315/55D20 (non-marking)
Power
-
Power source(optional)
36.3 kW/2800 rpm/D2011L3I/Deutz/EU Stage 3A/EPA Tier 3 -
Auxiliary Power Unit
12V DC -
Fuel Tank Capacity-Diesel
55L -
Hydraulic Tank Capacity
90L
-
Weight
7,280 kg -
Standards Compliance
AS/NZS1418
Standard features
- Oscillating function
- 7-in display screen
- 4WD × 2WS
- Proportional control with 3 joysticks
- 160° Platform rotation
- Max tilt rating to 5°
- 1.83m(6') platform
- Non-marking tires
- Secondary guarding system
- Half Mesh
- Telematics-ready connector
- White noise alarm
- Lockable battery isolator
Optional features
- AC power to platform
- Harness tube
- Wheel nut indicator
- Fire extinguisher
- Full mine spec
